Overview

• Based on extensive experience manufacturing products and years of service utilizing specialty anodes for vertical anode applications.
• Designed and assembled using high quality materials manufactured in North America to the highest standards. Items are stocked for immediate assembly and quick shipping.
• Industry leading venting system ensures generated gases are vented efficiently providing optimum anode performance.
• Multi-component, chemical resistant layered anode-to-cable splices.

Features & Benefits

• North American assembled for quick shipping to job sites.
• Reel-mounted assembling prevents damage and facilitates fast installation.
• Premium HALAR/HMWPE chemical resistant cable option. + Suitable for any hole diameter larger than 6".
• Built-in redundancy, including looped cable system and multiple cable to anode splices.
• Light weight anode system reducing transportation costs for your project.
• Multiple current outputs and life expectancy ensuring the anode system meets your project requirements.
• Vent system is directly connected to anode ensuring immediate gas venting.

Fully Customized Ordering

Customized anode output:

• 150 mA/linear foot–40 year design life*
• 250 mA/linear foot–40 year design life*
• 300 mA/linear foot–20 year design life*
• 500 mA/linear foot–20 year design life*

* Based on well backfilled with carbon/coke for anode section.

Cable Selection

Can be ordered with either of the below cable types:

• HMWPE—High Molecular Weight Polyethylene—Standard Cathodic protection cable for shallow anodes.
• HALAR/HMWPE—Chemical resistant, recommended for deep well applications.

Note: To avoid drying the anode, limit the current density at the coke column-soil interface to 100 mA/sqft in clay and 150 mA/sqft in other soils.
